Product Number:
CBL2640
Availability:
Out of Stock
Price:
$79.99 CAD


  Description

This throttle cable profile is commonly applicable for many big brand and lesser brand name machines from all over the world. Common format for ATVs, UTVs (side-by-side), carts, buggies and other machine types in the 300cc to 1000cc range.

This particular model was primarily stocked as direct replacement throttle cable for Xinyang (aka Xingyang, XY) UTV models XY500A, XY500B, as well as Chironex Spartan UTV Models "Spartan 500cc" and "Spartan 600cc".

Most commonly used for (but not limited to) Chironex Spartan 500cc UTVs (4x4/2x4 and similar variations), Chironex Spartan 600cc UTVs (4x4/2x4 and similar variations), Xinyang 500cc UTVs, (4x4/2x4 and similar variations) and Xinyang 600cc UTVs, (4x4/2x4 and similar variations).

Common Chironex model name is primarily listed as "Chironex 500cc or 600cc Spartan XUV or UTV". Listed as "ACCELEROGRAPH LINE" in their parts lists.

Common Xinyang model names consist of variations of "Xinyang XY500A" and "Xinyang XY500B", as well as a range of other suffixes and less formal names such as "Xinyang 500cc or 600cc UTV", "Xinyang 500cc or 600cc XUV", "Xinyang 500cc or 600cc 4x4/2x4" etc. Listed as "ACCELEROGRAPH LINE" in their parts lists.

  • Total Core Wire Length: 205cm
  • Sheath Length: 190cm
  • Thread Type: M10
  • Cable Travel Length: 14.4cm
  • Cable Stops: 5.9mm (on one end only)
    Manufacturer PN: 58310-5000
